The MCDODO CP-5980 is a 70W five-port wall charger in the MDD G5 Series. Weight: 163g. Input: 100–250V~50/60Hz, 1500mA (global voltage). Socket: 10A max, 2500W max. USB-C1: 70W max (5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A, 20V⎓3.5A; PPS 3.3–11V⎓5A). USB-C2 / USB-C3: 5V⎓3A each. USB-A1 + USB-A2 combined: 5V⎓3A. Combined when USB-C1 active: 45W + 15W. No certifications listed. Package: wall charger, Type-C cable, English and Chinese manual. Curated by Aetheo.
Why you'll like it
- 70W via USB-C1 — fast charging for compatible laptops and phones
- Five ports — USB-C1, USB-C2, USB-C3, USB-A1, USB-A2
- 100–250V global voltage input — suited to international travel
- PPS 3.3–11V⎓5A on USB-C1 for compatible devices
- Type-C cable included
Designed for a multi-device charging setup at a single wall socket
The MCDODO CP-5980 provides five ports — three USB-C and two USB-A — from a single mains plug. USB-C1 delivers up to 70W for fast-charging laptops and phones. USB-C2 and USB-C3 each output 5V⎓3A. USB-A1 and USB-A2 share a combined 5V⎓3A limit. Input accepts 100–250V for use across global mains voltages. PPS is supported on USB-C1 at 3.3–11V⎓5A. A Type-C cable is included. Curated by Aetheo.
Key features
USB-C1 — 70W max with PPS
USB-C1 delivers up to 70W at the following outputs: 5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A, or 20V⎓3.5A. PPS is supported at 3.3–11V⎓5A for compatible devices requiring fine-grained voltage control. This is the highest-power port on the unit and is intended for laptops, tablets, or phones with fast-charging support.
USB-C2 and USB-C3 — 5V⎓3A each
USB-C2 and USB-C3 each output 5V⎓3A (15W). These ports provide standard USB-C charging for phones and accessories but do not support higher-voltage fast charging. No Quick Charge protocol is listed in the source specification.
USB-A1 and USB-A2 — 5V⎓3A combined
The two USB-A ports share a combined output of 5V⎓3A. This limits simultaneous use — both ports together do not provide 5V⎓3A each independently. Suitable for lower-power accessories and phones with standard USB-A charging.
Combined output — USB-C1 active
When USB-C1 is active alongside the remaining ports, the combined output structure is: USB-C1 portion: up to 45W; remaining ports (USB-C2, USB-C3, USB-A1, USB-A2): up to 15W combined. When only USB-C2, USB-C3, USB-A1, and USB-A2 are active (without USB-C1), all four ports share 5V⎓3A.
100–250V global input — 163g
Input accepts 100–250V~50/60Hz at 1500mA, covering standard mains voltages globally — 100V (Japan), 110–120V (North America), and 220–250V (UK, Europe, Australia). Socket rated at 10A max, 2500W max. Weight: 163g. No certifications are listed in the source specification. No Quick Charge protocol is listed.
Best for
- 70W USB-C1 fast charging for laptops and phones
- Five-port multi-device charging from a single wall socket
- 100–250V global mains voltage input for international travel
- PPS 3.3–11V⎓5A on USB-C1
- Type-C cable included
What's included
- 1 × MCDODO CP-5980 Wall Charger
- 1 × Type-C Cable
- 1 × English and Chinese Manual
Compatibility and setup
Brand: MCDODO. Model: CP-5980 (MDD G5 Series). Weight: 163g. Input: 100–250V~50/60Hz, 1500mA. Socket: 10A max, 2500W max. USB-C1: 5V⎓3A / 9V⎓3A / 12V⎓3A / 15V⎓3A / 20V⎓3.5A (70W max); PPS 3.3–11V⎓5A. USB-C2 / USB-C3: 5V⎓3A each. USB-A1 + USB-A2: 5V⎓3A combined. Combined (C1 active): up to 45W + 15W. Combined (C2/C3/A1/A2 only): 5V⎓3A. Quick Charge: not listed. Certifications: not listed. Included: wall charger, Type-C cable, English and Chinese manual.
Why choose the MCDODO CP-5980 wall charger?
The MCDODO CP-5980 is a 70W five-port wall charger — MDD G5 Series, 163g, 100–250V global input, USB-C1 70W max (5V⎓3A / 9V⎓3A / 12V⎓3A / 15V⎓3A / 20V⎓3.5A, PPS 3.3–11V⎓5A), USB-C2/C3 5V⎓3A each, USB-A1+A2 5V⎓3A combined, combined structure: 45W+15W when C1 active. No Quick Charge protocol listed. No certifications listed. Type-C cable and English/Chinese manual included. Curated by Aetheo.
Complete your routine
Explore more curated technology and everyday wellness essentials from Aetheo, designed to make modern living feel simpler, calmer and more considered.
FAQs
What is the maximum output of the MCDODO CP-5980?
USB-C1 delivers up to 70W (20V⎓3.5A). USB-C2 and USB-C3 deliver 5V⎓3A each (15W each). USB-A1 and USB-A2 share a combined 5V⎓3A output. PPS on USB-C1 supports 3.3–11V⎓5A for compatible devices. No Quick Charge protocol is listed in the source.
| Specification | Details |
|---|---|
| Brand | MCDODO |
| Model | CP-5980 (MDD G5 Series) |
| Weight | 163g |
| Input | 100–250V~50/60Hz, 1500mA |
| Socket Rating | 10A max, 2500W max |
| USB-C1 Output | 5V⎓3A / 9V⎓3A / 12V⎓3A / 15V⎓3A / 20V⎓3.5A (70W max); PPS 3.3–11V⎓5A |
| USB-C2 / USB-C3 Output | 5V⎓3A each |
| USB-A1 + USB-A2 Combined | 5V⎓3A combined |
| Combined (C1 active) | 45W (C1) + 15W (C2/C3/A1/A2) |
| Combined (C2/C3/A1/A2 only) | 5V⎓3A |
| Quick Charge Protocol | Not listed |
| Certifications | Not listed |
| Included | Wall charger, Type-C cable, English and Chinese manual |
